Electrical Conduit Types and Fittings

electrical conduit

As an electrician or apprentice, you will have conduit as a constant companion throughout your career. Getting familiar with them can quickly advance your learning curve. But what exactly are all the various electrical conduit types and fittings? We’ll help you answer those questions in this edition of Training the Apprentice.


What is Electrical Conduit?

In general, conduit is a channel or pathway that can apply to many different areas. Roadways can be traffic conduits, ditches can be conduits for water, websites are a conduit for information.

When we’re talking about electrical conduit, we’re talking about the physical pathways you create in order to run wiring in a building. They serve to guide and protect wiring.

There are several different types of conduit you may use over the course of your career, and you’ll find specific details of how and when to use it in the National Electrical Code and other state and local building codes.

It’s All About Pathways

The basic idea is that you’ll create a logical pathway from the box to every point in the building that requires electricity in a way that is almost completely hidden once the walls and ceilings are in place. There may be some conduit that remains visible on the exterior of buildings, in open ceiling structures, electrical rooms, and others.

electrical conduit

Once you install the electrical conduit paths, you pull wire through them to your termination points.

Electrical Conduit Types and Acronyms

You’ll hear several acronyms tossed around when you’re talking about types of electrical conduit along with terms like “rigid” and “flexible”. Here’s a breakdown of the most common types of electrical conduit.

RMC: Rigid Metal Conduit

RMC stands for “rigid metal conduit”. It’s one of the most heavy-duty types of electrical conduit and uses galvanized steel for its construction. As an outdoor-friendly conduit, it provides outstanding protection from environmental and physical damage. It’s also capable of providing structural support for boxes, cables, and other electrical equipment.

electrical conduit
  • Typical Fastening Style: Threaded
  • Common Sizes: 1/2″ – 2-1/2″
  • Common Applications: Outdoor installations

IMC: Intermediate Metal Conduit

Intermediate metal conduit (IMC) is a toned-down version of RMC that’s thinner and lighter. Even though it’s not as thick, it’s typically approved for all of the same applications as RMC. Given the choice between the two, our electricians prefer IMC simply because its lighter weight makes it much easier to deal with.

  • Typical Fastening Style: Threaded
  • Common Sizes: 1/2″ – 2-1/2″
  • Common Applications: Outdoor installations

EMT: Electrical Metallic Tubing

Around our Pro team, EMT is the most common term thrown around when we’re talking about types of electrical conduit. Some of the new guys and gals use it as a catch-all term for all metal conduit, but that’s not actually correct.

EMT stands for “electrical metallic tubing” and is a type of rigid metal conduit. You normally see it made from galvanized steel and it also shows up as aluminum in some cases.

Milwaukee Conduit Bender

As a thinner metal tube, it’s easy to bend and kink. When you’re installing EMT, you use a conduit bender to make your bends without kinking and a compact or 12V reciprocating saw with a high TPI blade is all you need to cut it.

  • Typical Fastening Style: Compression
  • Common Sizes: 1/2″ – 1″
  • Common Applications: Residential and light commercial indoor (watertight fittings required for outdoor use)

FMC: Flexible Metal Conduit

Way back before most of us were born (the early 1900s), Harry Greenfield invented a flexible metal conduit (FMC).  Using steel or aluminum for construction, it has a distinct spiral look to it that allows it to flex over short distances much easier than EMT. It has a big advantage when you need to add conduit in tight spaces or around existing equipment.

Types of Electrical Conduit - Flexible Metal Conduit
  • Typical Fastening Style: Threaded
  • Common Sizes: 1/2″ – 4″
  • Common Applications: Indoor

LFMC: Liquid-Tight Flexible Metal Conduit

LFMC, or liquid-tight flexible metal conduit, is similar to FMC but covered in a waterproofing coating. It’s useful for outdoor applications and wet interior areas and requires fittings that are also watertight.


  • Typical Fastening Style: Threaded
  • Common Sizes: 1/2″ – 4″
  • Common Applications: Outdoor and indoor wet areas

ENT: Electrical Non-Metallic Tubing

Electrical non-metal tubing (ENT conduit) is different from the other types of electrical conduit we’ve discussed so far in several ways. It’s a flexible PVC tubing that looks a lot like a pool hose.

You can encase it in concrete, run it behind walls and under floors, and use it as a replacement for EMT. The major manufacturer for ENT uses 2-hour fire resistant rated materials. ENT is not UV-resistant, though, so using it where it will be exposed to UV rays is out.

  • Typical Fastening Style: Snap-lock or glue
  • Common Sizes: 1/2″ – 2″
  • Common Applications: Indoor

Rigid PVC Conduit

Rigid PVC is a very familiar material to many folks thanks to its similarities to the PVC we use in plumbing and irrigation. Unlike EMT, you can’t use a conduit bender to manipulate it. PVC needs to be heated before in order to bend it. Typically that happens using a heater box but you can use a heat gun as an alternative in the field.

As a conduit, rigid PVC shares the same characteristics as water pipe: you glue it together and it’s water-tight when you install it correctly. That makes it useful for direct burial underground and it’s allowable in corrosive environments. You can also encase it in concrete, conceal it in walls, or leave it exposed.

  • Typical Fastening Style: Glue
  • Common Sizes: 1/2″ – 5″
  • Common Applications: Outdoor, indoor, underground

Related articles

Stanley Black and Decker Completes Acquisition of MTD Holdings and Excel Industries

Stanley Black and Decker Strengthens Portfolio with Acquisitions in Outdoor Power Equipment Industry Stanley Black and Decker (“SBD”) announced today that it has successfully completed the acquisition of both MTD Holdings Inc. (“MTD”) and Excel Industries (“Excel”). Both MTD and Excel are industry leaders in the $25 billion+ outdoor power equipment market, and Stanley Black […]

Ryobi vs DeWalt – Which Tool Brand Reigns Supreme?

Readers—be they professional or tool enthusiasts ask us about two key brands more than any others: Ryobi and DeWalt. However, in the Ryobi vs DeWalt debate, the issue isn’t so much which brand is more Pro. The real question is whether Pros can accomplish the work needed with a lesser-priced, budget-saving tool versus a more […]

Makita Direct Repair Service – Everything You Need To Know

Makita Direct Repair Service Gives Users More Convenience and Less Downtime Regular usage on the jobsite will test the limits of even the most durable tools. Sometimes, those tools require repairs or servicing. That’s why Makita is committed to fast after-sale service, as evidenced by their new Direct Repair online program. Makita has designed the […]

Makita Black Friday Deals for 2021

If You Like Tools, These Makita Black Friday Deals Will Rock Your World All of the 2021 Makita Black Friday deals are live, and some of them are downright amazing! As always, you can grab discounts on batteries and tool combo kits, but even individual tools show dramatic savings for those looking to expand the […]

Subscribe
Notify of
guest
5 Comments
Newest
Oldest Most Voted
Inline Feedbacks
View all comments
Jim S

Think it’s funny that FMC and LFMC are listed as 1/2″ to 4″ for common sizes, but GRC and IMC only to 2 1/2″ and EMT 1/2″-1″

Gerry Q

You should mention that rigid PVC comes in schedule 40 & 80 (or more). When exposed in areas where mechanical damage is likely, schedule 80 is required. Knew a guy who installed about $ 400 of sched 40 in a cattle barn only to be told by the inspector to tear it all out and replace with sched 80!

Michael Petrik

You missed Robroy, or PVC coated conduit for corrosive environments. Fun stuff that is!!
