Makita Expands LXT Platform With New Drywall, Decking Screwdriver
A few years ago, Makita released a brushless update to its screw gun lineup with the XFR03. Now, we’re seeing the next iteration of that tool, the Makita XRF04 Autofeed Screwdriver. At first glance, it may seem like not much has changed, but I’m digging deeper into this model to help you decide if it’s worth the upgrade.
Makita 18V LXT Autofeed Screwdriver Overview
- Model: Makita XRF04
- Weight: 4.9 lbs (with battery)
- Length: 15 5/8 inches
- Brushless Motor
- Max Speed: 4500 RPM
- Screw Capacity: 1-inch to 2 3/16-inch
- Push Drive Technology
The XRF04 is Makita’s most recent autofeed screwdriver. Like the last iteration (XRF03), it features a brushless motor; however, it actually lowers the maximum speed to 4500 RPM, compared to the XRF03’s 6,000 RPM max.
While this may allow for a higher torque level, 4,500 RPM is nothing to shake a stick at. In fact, it’s likely a very intentional move on the design team’s part, prioritizing higher torque levels than we’ve seen previously. However, Makita doesn’t provide any specific torque figures for either model. Regardless, it’s a speed that’s in line with Milwaukee, DeWalt, and other close competitors.
This tool carries over the Push Drive technology that we saw in previous models, including the XRF03 and XSF03. In lock-on mode, this function activates the motor only when the fastener engages, leading to more battery efficiency and translating into the longer runtimes we see with this model.
The XRF04 is compatible with collated screws from 1 inch to 2 3/16 inches in length for a variety of drywall, decking, and framing applications. Using a 5.0Ah battery (sold separately), you can drive up to 2670 screws per charge. This is an increase of more than 400 screws per charge over the previous model using the same battery, meaning you won’t need to interrupt your workflow as often to swap batteries.
Additional Features
- Lock-On Button: Enables continuous use coupled with Pulse Drive Technology.
- One-Touch Housing Hook: Attach and remove the autofeed housing easily when changing screw strips.
- Reversible Belt Clip: Fix the belt clip to either side of the tool for primary use with either hand.
- Screw Guide: Prevents screw strip tangling.
How Does it Compare?
Here’s a look at the XRF04 and the previous iteration, the XRF03, side-by-side for a direct comparison.
| Makita XRF04 (This model) | Makita XRF03 | |
|---|---|---|
| Max Speed: | 4,500 RPM | 6,000 RPM |
| Weight: | 4.9 lbs | 4.9 lbs |
| Screw Capacity: | 1-inch to 2 3/16-inch | 1-inch to 2 3/16-inch |
| Runtime: | 2,670 screws | 2,250 screws |
| Price (Bare Tool): | $429 | $434 |
Makita 18V LXT Autofeed Screwdriver Price
This tool retails for $429 as a bare tool, and you can find it at Acme Tools or other Makita retailers. Currently, there are no kit options available, so be sure to pick up a Makita 18V LXT battery and charger if you’re not already on this platform. Makita backs your purchase with a 3-year warranty.
Should You Buy It?
The XRF04 maintains many of the performance and design features we saw in Makita’s previous Autofeed Screwdriver, and even delivers increased runtime for fewer workflow breaks. If you’re after a cordless driving solution for drywall or framing jobs, the XRF04 is worth considering for those already on Makita’s LXT system.
However, if you already own the previous iteration and you’re wondering if you should upgrade to the newest model… well, you’re probably fine with sticking with what you have. While the added runtime is a bonus, I don’t think it’s enough to justify spending over $400 on a new tool unless you’re serious about the extra runtime per charge. Then again, an extra battery would do the trick just as well.
